Direct Input Box Build
This project was a DI Box I built for a class in my undergrad. Parts were sourced from various electronics and circuitry websites, and then first assembled on a bread board. Following successful testing on the bread board, the build was duplicated for the enclosure, soldered, and closed.
For more pictures, frequency response, signal to noise, and a spectrogram click here.
Microphone Preamp Build
Another project I worked on was a Microphone Pre that I built. I used a schematic from the internet and modified it. I also removed the 48V phantom power, since this was a bit more complicated for one of my first builds.
For more pictures, frequency response, signal to noise, and a spectrogram click here.
Mock Studio Acoustics Build
This was a final project for an undergrad acoustics project. The goal was to create a layout for a control room and live room, and have the RT60 times for both spaces land within a target range. Additionally, necessary materials for appropriate isolation were listed.
For the full project click here.
